It is suitable for all kinds of PVC,PET,PP,CPP,OPP plastic sheet, rubber magnetic sheet, paper magnetic sheet, paper, leather, sizing cloth, self-adhesive paper, trademark paper, copper foil, metal foil and other whole roll film to flatten, slice, strip, winding, laminating etc.
| MODEL | HSD-7080A |
| POWER Range | 15KW |
| Input Power | 25KVA |
| Suitable Welding Area | 400CM2 |
| Oscillation Tube | 8T85RB |
| Standard working table | 700*850 |
| Power Supply | 3P * 380V * 50Hz & 3P * 220V * 60Hz |
| Working Frequency | 27.12Mhz |
| Rectifier | Silicon Diode |
| Drive Mode | Pneumatic & Hydraulic |
| Arc suppressor | High Sensibility PL-5557 |
| Cylinder working stroke | 150mm ( customization offered ) |
| Welding Time | 0-30 S adjustable ( customization offered ) |
Features: Controlled by PLC microcomputer, automatic display and adjustment of the machine's running data and operation procedures are simple, convenient, high production efficiency, slice length and width error is less than 0.1MM. This equipment automatically feeding, flattening, strip, winding, laminating, slicing, automatic feeding
