Daily chemical industry: Applicable to the packaging and sealing of hair care products, cosmetics, cleaning and washing products, etc.
Gift and craft industry: Applicable to the cylindrical packaging of various gifts and crafts.
Toy industry: Applicable to the cylindrical packaging and sealing of toys.
Hardware and machinery industry: Applicable to the cylindrical packaging and sealing of hardware and mechanical products
High efficiency: The speed is extremely high, depending on the worker's operating speed. According to feedback records, the speed record of gluing the bottom cover of the cylinder is kept at 1.5s/piece.
Accuracy: The German Siemens microcomputer PLC control system is adopted to improve system stability and reduce machine failure rate, which is convenient for operation and adjustment.
Automation: Automatic gluing, forward and backward functions, etc., eliminate the shortcomings of traditional hand-dipping glue.
High quality: Replace traditional manual operation, solve the problems of high scrap rate of manual operation, uneven glue, fingerprints on the bonding part, etc.
| Model | HSD-GR-500 |
| Power supply | 3*P220v 2KW |
| Station | 1- workstations |
| Bottom cover diameter | 40-200MM |
| Thickness | 0.15-0.6MM |
| Production speed | 400-500pieces/hour |
| Adhesion accuracy | ≤±0.03PLC control, 8-position precise divider positioning |
| bonding process | Blister cover |
| Applicable materials | PVC,PETG,APET |
| Cylinder length | 20mm-500mm |
| Cylinder dia | 40-200mm (adjustable) |
